T600 Mid-Range Desktop Thermal Printer
The T600 is an exceptional mid-range thermal desktop printer for applications that require reliability, versatility and ease-of-use.
PRODUCT BENEFITS
Thermal Transfer and Direct Thermal printing
32-bit RISC high performance processor
2.3: Color Display w/6 button control
32GB SD Card option
Double wall clamshell construction
Available in 203 DPI and 300 DPI
64 MB SDRAM / 128 MB Flash Memory
4” model configuration
PRINTING CHARACTERISTICS
Max Print Speed: 6 IPS @ 203 DPI / 4 IPS @ 300 DPI
Print Method: Thermal Transfer and Direct Thermal
Resolution: 203 DPI or 300 DPI
Max. Print Width: 4.25” (108mm) 4.15″ (105.6mm)
Printer Memory: 64MB RAM / 128MB Flash
Ribbon Length 110m, max OD 40mm, 0.5″ core (ink coated out)
MEDIA SPECIFICATIONS
Media Applications: Product marking, point of sale, retail, small office, shipping labels, and other labeling and tag application
Min. Media Width: (4”) 0.79″ (20mm)
Max. Media Width: 4.4” (112mm)
Min. Media Length: 0.39”(10mm)
Max. Media Length: 1000” (25,400 mm)
Media Thickness: 2.36 mil(.06mm) to 7.48 mil(.19mm)
Media Roll Core Diameter: 1.0” (25.4mm) to 1.5″ (38.1mm)
Max. Media Roll Diameter: 5.0” (127mm)
Media Sensing: Transmissive gap sensor, black mark reflective sensor, head open sensor, ribbon end sensor
Media Type: Continuous, die-cut, black mark, fan-fold, notched (outside wound)
MEDIA HANDLING MODES
Standard: Continuous, Tear-Off Strip
Options: Peel-Off, Cut
PHYSICAL CHARACTERISTICS
Width: 7.99” (203mm)
Height: 7.54”(191.5mm)
Depth: 10.21” (259.3mm)
Printer Weight: 5.07lbs (2.3kg)
Shipping Weight: 8.03lbs (3.65kg)
PRINTER LANGUAGE
Printer Languages: DPL, EPL, ZPL, ZPL2
COMMUNICATION & CONNECTIVITY/INTERFACE
Standard Interface I/O: Serial RS232, USB 2.0 , and Ethernet 10/100Base T
Display: 2.3″ 320 x 240 color TFT Display w/6 button control
OPERATING ENVIRONMENT
Operating Temperature: 40 to 104 °F (5 to 40 °C)
Operating Humidity: 20 – 85% Non-Condensing
Storage Temperature: -40 to 140 °F (-40 to 60 °C)
Storage Humidity: 10 – 90% Non-Condensing
POWER REQUIREMENT
Line Input: Auto Range AC 100-240V, 50-60Hz
Printer Output: DC 24V, 2.5A, 60W
REGULATORY COMPLIANCES
Emissions: FCC Class B, CE,
Safety: cULus, CE
Environmental: RoHS, WEEE, ENERGY STAR®
BARCODE SYMBOLOGIES
1D Barcodes: Code 39, Code 39 with check digit, Code 93, Code 128UCC, Code 128 subset A, B, C, Codabar, Interleave 2 of 5,Interleaved 2 of 5 with check digit, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, MSI, MSI with check digit, PLESSEY,POSTNET, Logmars, Code 11,Code 49, China post, ITF14, TELEPEN, TELEPENN, PLANET, Deutsche Post Identcode,Deutsche Post Leitcode
2D Barcodes: GS1 DataBar, GS1 DataMatrix, Maxicode, AZTEC, PDF417, QR Code, Micro PDF 417
FONT, GRAPHIC SUPPORT
Internal Fonts: 8 alpha-numeric bitmap font Monotype Image® true type font engine with one CG Triumvirate Bold Condensed scalable font
Font and barcode rotation: 0, 90, 180, 270 degree
OPTIONS AND ACCESSORIES
Peel & Present
Cutter
